Shacman Snowplow



The ShacmanL3000 snow removal truck is suitable for snow removal, melting, and sweeping on high-grade highways, urban roads, airports, squares, scenic areas, and other road sections. This vehicle is a special snow removal operation vehicle that integrates mechanical, hydraulic, and electrical components, and is equipped with a front snow shovel/sweeping roller brush and a snow melting spreader on the basis of the Shaanxi Automobile L3000 truck. The front of the car is equipped with a snow removal shovel/snow sweeping roller brush for interchangeable use. When there is heavy snow, the brush is used to sweep it to both sides of the road. When the snow is crushed by the car or frozen, the shovel is used to push it to both sides of the road. Rear mounted snow melting and spreading machine. During the winter snow removal process, the spreading machine throws wine and snow melting agent to prevent the slippery road surface from freezing and affecting traffic. Covering the road surface with snow melting agent can effectively solve the problem of road icing, allowing vehicles to pass safely without being affected by weather.

Technical parameters



Main specifications
Product model,name	Shacman snow removal Truck
Gross weight(Kg)	18000	Drive type		4 X 2
Payload (Kg)	8805	Overall dimension (mm)		8890X2500X3300
Curb weight(Kg)	9000	cab seats (man)		3
Approach / departure angle(°)	17/10	Front/rear hang(mm)		1430/2070
Number of axles	2	Wheelbase(mm)		4700
Axle load	4800/10000	Max speed(Km/h)		90
Chassis specifications
Chassis model	L3000	Manufacturer		Shacman
Tire specification	10.00R20	Tires No.		6
Steel spring number	7/9+6	Front track(mm)		1880
Fuel type	Diesel	Rear track(mm)		1860
Emission standard	Euro II	Transmission		8 speed Forward
Cabin	Luxury interior and Instrument bar, with air conditioning.
Spreader Parameter
volume (m³)	8	Spreading width	2-14m
Material of spreader	Carbon steel	Salt spraying amount	20-300g/m2
Distribution disk diameter	550mm	Working speed	5-45km/h
Snow shovel parameters
Snow removal width	3m	Left and right adjustment	±30 °
Speed	≧30km／h	Avoidant obstacle height	150mm



Configuration



Item	Part name	picture	function
1	Vehicle		Shacman L3000 chassis, body,snowspreading machine,plow
2	box		The box body / distributor material is made of Q235 carbon steel material, and the box body is formed at one time without splicing. Less welds can be hung less ash, reducing the risk of late paint loss.
3	Spreader disc		The main function of the distributor is evenly distributed on the road. The main material of the spreading tray is excellent carbon steel, and the spreading tray is made of stainless steel, driven by the hydraulic motor.



Feature



Characteristics of snow removal truck



1. The Shacman snowplow adopts shacman L3000 chassis, 210 hp engine, 8-speed gearbox, 4700mm wheelbase, and enjoys exemption policy, greatly saving costs.



2. In winter, it can clear snow and transport goods and rescue supplies, achieving multiple uses for one vehicle.



3. The operation inside the cab is safe and reliable, with an independent lighting system for easy night work.



4. The hydraulic system of the vehicle is reliable, efficient, has a short operating cycle time, and is easy to operate.



5. Low flat plate cargo box, made of high-quality carbon steel, with a thickness of 2 sides and 3 bottoms (mm). The box has a large capacity and can meet the needs of cargo transportation.



● Performance of snow shovel



1. Plowing type snow shovel, adjustable in both directions, with a left and right deflection angle of ≤ 30.



2. The snow removal shovel is easy and fast to install and disassemble, with good blade durability and easy replacement.



3. The avoidance of the snow removal shovel adopts the flipping of the shovel body. When any point of the snow removal blade encounters an obstacle, the snow removal shovel body flips to avoid.



● Performance characteristics of snow roller brush

1. Special material brush, long service life; The use of solid core high load-bearing wear-resistant support wheels greatly improves the reliability of snow sweeping roller brushes. The height of the roller brush off the ground and the grounding can be adjusted arbitrarily, improving work efficiency and achieving better results.



2. The deflection and lifting of the homework device are flexible and safe, the operation is adjustable, and it does not affect the function or performance of the original vehicle carrier; Equipped with anti snow devices, it will not cause snow to return and the road surface will be cleaned thoroughly.



Performance characteristics of snow melting agent spreader

1.It has multiple functions such as spreading salt and snow melting agent; The spreading width and amount can be adjusted and controlled, and the measurement is stable, accurate, and reliable.



2.Adopting carbon steel plate or stainless steel mechanism, the powertrain uses well-known domestic brand engines; The setting of spreading amount and spreading width can be directly operated in the cab.
